Части для соединения с прицепом (для тягачей)/Additional parts and fittings for trailer connections (for traktor)
Грузовые Автомобили Studebaker US6x6 имеют части для соединения с прицепом (для тягачей)/additional parts and fittings for trailer connections (for traktor). Этот узел состоит из различных элементов всего 130 шт. Все комплектующие для Studebaker US6x6 просто купить, перейдя на страницу продавца. Ниже, вы можете видеть чертеж в сборе части для соединения с прицепом (для тягачей)/additional parts and fittings for trailer connections (for traktor).
| № | Номер запчасти | Части для соединения с прицепом (для тягачей)/Additional parts and fittings for trailer connections (for traktor), все запчасти |
Где купить Части для соединения с прицепом (для тягачей)/Additional parts and fittings for trailer connections (for traktor) |
|---|---|---|---|
| 109144 | CLIP, Vacuum line pipe to cross member |
Найдено 0 продавцов |
|
| 11x120 | BOLT, hex. head 1/4"-28x5/8" |
Найдено 0 продавцов |
|
| 11x121 | BOLT, hex. head 1/4"-28x3/4" |
Найдено 0 продавцов |
|
| 11x123 | BOLT, hex. head 1/4"-28x7/8" |
Найдено 0 продавцов |
|
| 11x42 | BOLT, hex. head 5/16"-24x3/4" |
Найдено 0 продавцов |
|
| 11x7 | BOLT, hex. head 3/8"-24x7/8" |
Найдено 0 продавцов |
|
| 1501x2 | SCREW, support 5/16"x1/2" |
Найдено 0 продавцов |
|
| 172512 | CLAMP, Hand control valve pipes to frame support |
Найдено 0 продавцов |
|
| 172556 | HOSE, Hand control valve pipe to pedal valve 1/2"I.D.x12" long |
Найдено 0 продавцов |
|
| 181143 | CLIP, Pedal valve to booster hose |
Найдено 0 продавцов |
|
| 186912 | NIPPLE, hand control valve pipe |
Найдено 0 продавцов |
|
| 186913 | NUT, 1/2" pipe |
Найдено 0 продавцов |
|
| 20x81 | NUT, hex. 1/4"-20 |
Найдено 0 продавцов |
|
| 21x161 | NUT, hex. 1/4"-28 |
Найдено 0 продавцов |
|
| 21x2 | NUT, hex. 5/16"-24 |
Найдено 0 продавцов |
|
| 21x3 | В Части для соединения с прицепом (для тягачей)/Additional parts and fittings for trailer connections (for traktor) входит NUT, hex. 3/8"-24 |
Найдено 0 продавцов |
|
| 27x4 | NUT, hex. 1/4"-20 |
Найдено 0 продавцов |
|
| 40x431 | WASHER, lock 1/4" |
Найдено 0 продавцов |
|
| 40x432 | WASHER, lock 5/16" |
Найдено 0 продавцов |
|
| 40x433 | WASHER, lock 3/8" |
Найдено 0 продавцов |
|
| 55x140 | BOLT, hex. head 1/4"-20x1/2" |
Найдено 0 продавцов |
|
| 55x143 | BOLT 1/4"-20x7/8" |
Найдено 0 продавцов |
|
| 55x144 | BOLT, clip round head 1/4"-20x1" |
Найдено 0 продавцов |
|
| 61x18 | CLAMP, hose No.2 |
Найдено 0 продавцов |
|
| 61x20 | В Части для соединения с прицепом (для тягачей)/Additional parts and fittings for trailer connections (for traktor) входит CLAMP, hose to support spring - for 669605 hose No. 4.1/4 |
Найдено 0 продавцов |
|
| 631500 | TEE, Pedal valve (on valve) (for tractor) |
Найдено 0 продавцов |
|
| 631529 | NIPPLE, Booster cross (for tractor) |
Найдено 0 продавцов |
|
| 631539 | В Части для соединения с прицепом (для тягачей)/Additional parts and fittings for trailer connections (for traktor) входит ELBOW, Booster cross hose (for tractor) |
Найдено 0 продавцов |
|
| 632744 | ELBOW, Pedal valve to hand control pipe (for tractor) |
Найдено 0 продавцов |
|
| 633014 | COUPLING, Tee to vacuum line elbow |
Найдено 0 продавцов |
|
| 633016 | ELBOW, Shut-off valve to vacuum stop lamp switch |
Найдено 0 продавцов |
|
| 636258 | ELBOW, Shut-off valve hose, bottom right |
Найдено 0 продавцов |
|
| 638783 | NIPPLE, Pedal valve tee hose (for tractor) |
Найдено 0 продавцов |
|
| 642285 | ELBOW, Shut-off valve hose, bottom left |
Найдено 0 продавцов |
|
| 642286 | TEE, Vacuum line (check valve end) |
Найдено 0 продавцов |
|
| 642688 | CLIP, Hand control valve pipe hose to frame |
Найдено 0 продавцов |
|
| 642689 | NIPPLE, Shut-off valve hose, top left |
Найдено 0 продавцов |
|
| 666749 | SPRING, Trailer jumper hose support |
Найдено 0 продавцов |
|
| 666750 | CLIP, Trailer jumper hose spring to cab |
Найдено 0 продавцов |
|
| 666752 | VALVE ASSY., Trailer connection shut-off |
Найдено 0 продавцов |
|
| 666753 | STUD, SAFETY CLIP SPECIAL |
Найдено 0 продавцов |
|
| 666754 | CLIP, Jumper hose coupling safety |
Найдено 0 продавцов |
|
| 666802 | HOSE, Vacuum line pipe to booster 3/4"I.D.x25" long |
Найдено 0 продавцов |
|
| 666803 | HOSE, Pedal valve to booster 3/4"I.D.x50 1/4" long |
Найдено 0 продавцов |
|
| 667111 | HOSE, Vacuum line tee to pedal valve 3/4"I.D.x15" long |
Найдено 0 продавцов |
|
| 669390 | VALVE ASSY., Trailer connection hand control |
Найдено 0 продавцов |
|
| 669394 | SUPPORT, Shut-off valve and mounting bracket |
Найдено 0 продавцов |
|
| 669397 | HOSE, Hand control valve pipe to shut-off valve 1/2"I.D.x60" long |
Найдено 0 продавцов |
|
| 669398 | HOSE, Booster cross to right shut-off valve 3/4"I.D.x22" long (for tractor) |
Найдено 0 продавцов |
|
| 669492 | CLAMP, Hand control valve steering post - with clamp bolts |
Найдено 0 продавцов |
|
| 669507 | SUPPORT, Hand control valve pipes to frame |
Найдено 0 продавцов |
|
| 669509 | PIPE WITH NUTS, Hand control valve control |
Найдено 0 продавцов |
|
| 669510 | PIPE WITH NUTS, Hand control valve vacuum |
Найдено 0 продавцов |
|
| 669511 | CLAMP, Hand control valve pipes to steering post |
Найдено 0 продавцов |
|
| 669605 | HOSE, Trailer control jumper 1/2"I.D.x108" long |
Найдено 0 продавцов |
|
| 669606 | HOSE. Trailer vacuum jumper 3/4"I.D.x108" long |
Найдено 0 продавцов |
|
| 669607 | COUPLING, Trailer control jumper hose |
Найдено 0 продавцов |
|
| 669608 | COUPLING, Trailer vacuum jumper hose |
Найдено 0 продавцов |
|
| 669725 | CROSS, Booster - 1/2" std. pipe (for tractor) |
Найдено 0 продавцов |
|
| 669726 | REDUCER, Shut-off valve mounting bracket tee pipe |
Найдено 0 продавцов |
|
| 669727 | NIPPLE, Vacuum stop lamp switch pipe |
Найдено 0 продавцов |
|
| 669728 | ELBOW, Vacuum stop lamp switch to booster hose |
Найдено 0 продавцов |
|
| 669730 | SWITCH, Stop lamp - vacuum type (located under left trailer connection shut off valve) |
Найдено 0 продавцов |
|
| 669731 | HOSE, Vacuum stop lamp switch to booster 1/4"I.D.x23" |
Найдено 0 продавцов |
|
| 669770 | BOLT, clamp 5/16"-18x2.1/8" |
Найдено 0 продавцов |
|
| 669775 | BRACKET, Shut-off valve mounting |
Найдено 0 продавцов |
|
| 669776 | TEE, Shut-off valve mounting bracket pipe |
Найдено 0 продавцов |
|
| 669777 | REDUCER, Shut-off valve right mounting bracket pipe |
Найдено 0 продавцов |
|
| 669781 | PIPE, Vacuum line (check valve to booster hose) (3/4" 0.D.x45 1/2" long with fitting) |
Найдено 0 продавцов |
|
| 670143 | HAND CONTROL VALVE REPAIR KIT - Consists of all necessary parts to repair hand control valve |
Найдено 0 продавцов |
|
| 99x10 | CLAMP, hose to coupling - for 669605 hose 15/16" |
Найдено 0 продавцов |
|
| 99x11 | CLAMP, hose to support spring - for 669606 hose 1.3/16" |
Найдено 0 продавцов |
